Cirrus Clouds Viewed with the 13.3 Micron Channel

This image shows cirrus clouds viewed with the GOES-12 13.3 micron carbon dioxide channel

• Brightness temperature influenced by emission from tropospheric carbon dioxide
• Brightness temperatures colder and more uniform than for longwave infrared window due to CO₂
• Cooling relative to longwave infrared window useful for cloud height determination
• More sensitive to thin cirrus (brightnes temperature colder) than for longwave infrared window
• Motion helpful in identifying thin cirrus
